Proline Promag P 300
electromagnetic flowmeter

F

L

E

X

Products

Flow measurement

High-temperature flowmeter for process applications with a compact, easily accessible transmitter

Predecessor: Promag 50P , Promag 51P , Promag 53P , Promag 50E , Promag 53E

Show specs at a glance Hide details

Max. measurement error

Volume flow (standard): ±0.5 % o.r.± 1 mm/s (0.04 in/s)
Volume flow (option): ±0.2 % o.r. ± 2 mm/s (0.08 in/s)

Measuring range

4 dm³/min to 9600 m³/h (1 gal/min to 44 000 gal/min)

Medium temperature range

Liner material PFA: –20 to +150 °C (–4 to +302 °F)
Liner material PFA high-temperature: –20 to +180 °C (–4 to +356 °F)
Liner material PTFE: –40 to +130 °C (–40 to +266 °F)

Max. process pressure

PN 40, Class 300, 20K

Wetted materials

Liner: PFA; PTFE
Electrodes: 1.4435 (F316L); Alloy C22, 2.4602 (UNS N06022); Tantalum; Platinum; Titanium
Loading price

Prices temporarily unavailable

Price after login

Price on request

from CHF ??.-
Compare
F

L

E

X
Proline Promass F 300
Coriolis flowmeter

F

L

E

X

Products

Flow measurement

Flowmeter with premium accuracy, robustness and a compact, easily accessible transmitter

Predecessor: Promass 80F , Promass 83F , Promass 84F

Show specs at a glance Hide details

Max. measurement error

Mass flow (liquid): ±0.10 % (standard), 0.05 % (option)
Volume flow (liquid): ±0.10 %
Mass flow (gas): ±0.25 %
Density (liquid): ±0.0005 g/cm³

Measuring range

0 to 2 200 000 kg/h (0 to 80 840 lb/min)

Medium temperature range

Standard: –50 to +150 °C (–58…+302 °F)
Option: –50 to +240 °C (–58…+464 °F)
High temperatur option: –50 to +350 °C (–58…+662 °F)
Option: –196 to +150 °C (–320 to +302 °F)

Max. process pressure

PN 100, Class 600, 63K

Wetted materials

Measuring tube: 1.4539 (904L); 1.4404 (316/316L); Alloy C22, 2.4602 (UNS N06022)
Connection: 1.4404 (316/316L); Alloy C22, 2.4602 (UNS N06022); 1.4301 (F304)
Loading price

Prices temporarily unavailable

Price after login

Price on request

from CHF ??.-
Compare
F

L

E

X
4-channel transmitter
Liquiline CM444

F

L

E

X

Products

Analysis

Expandable multiparameter field device for all industries

Predecessor: CCM360 , Sludge level CUM750

Show specs at a glance Hide details

Input

1 to 4x Memosens digital input
2x 0/4 to 20mA Input optional
2 to 4x Digital input optional

Output / communication

2 to 8x 0/4 to 20 mA current outputs, alarmrelay,
4x relay, ProfibusDP, Modbus RS485, Modbus TCP, Ethernet

Ingres protection

IP66 / IP 67
Loading price

Prices temporarily unavailable

Price after login

Price on request

from CHF ??.-
Compare
F

L

E

X
Digital pH sensor
Orbisint CPS11D

F

L

E

X

Products

Analysis

Memosens glass electrode for standard applications

Show specs at a glance Hide details

Measurement range

pH 0 to 14

Process temperature

0 to 135 °C (32 to 275 °F)

Process pressure

1 to 17 bar (15 to 246 psi)
Loading price

Prices temporarily unavailable

Price after login

Price on request

from CHF ??.-
Compare
F

L

E

X
Radar measurement
Time-of-Flight
Micropilot FMR20

F

L

E

X

Products

Level

Level measurement of liquids and solids in all industries

Show specs at a glance Hide details

Accuracy

+/- 5 mm (0.2")

Process temperature

-40…+80°C (-40…+176°F)

Process pressure absolute / max. overpressure limit

-1…3 bar (-14,5…43 psi)

Max. measurement distance

DN80: 10 m (32.8 ft)

Main wetted parts

PVDF, PBT
Loading price

Prices temporarily unavailable

Price after login

Price on request

from CHF ??.-
Compare
F

L

E

X
Radar measurement
Micropilot FMR60

F

L

E

X

Products

Level

The standard sensor for highest demands in liquid level measurement with 80GHz technology

Show specs at a glance Hide details

Accuracy

+/- 1 mm (0.04 in)

Process temperature

-40…+130 °C
(-40…+266 °F)

Process pressure absolute / max. overpressure limit

Vacuum …16 bar
(Vacuum … 232 psi)

Max. measurement distance

50 m (164 ft)

Main wetted parts

PTFE antenna
PP or 316L process connections
Loading price

Prices temporarily unavailable

Price after login

Price on request

from CHF ??.-
Compare
F

L

E

X
Liquiphant FTL51B - digital, simple and safe

F

L

E

X

Products

Level

Point level switch for all liquid media

Predecessor: Liquiphant M FTL51 , Liquiphant M FTL50

Show specs at a glance Hide details

Process temperature

-50 °C...+150 °C
(-58 °F...+302 °F)

Process pressure absolute / max. overpressure limit

Vacuum...100 bar
Vacuum...1450 psi

Min. density of medium

0.5 g/cm³
(0.4 g/cm³ optional)
Loading price

Prices temporarily unavailable

Price after login

Price on request

from CHF ??.-
Compare
F

L

E

X
Liquiphant FTL62 - the coated sensor for aggressive media

F

L

E

X

Products

Level

A level switch for aggressive and pumpable liquids

Predecessor: Liquiphant M FTL51C

Show specs at a glance Hide details

Process temperature

-50 °C...+150 °C
(-58 °F...+302 °F)

Process pressure absolute / max. overpressure limit

Vacuum...40 bar
Vacuum...580 psi

Min. density of medium

0.5 g/cm³
(0.4 g/cm³ optional)
Loading price

Prices temporarily unavailable

Price after login

Price on request

from CHF ??.-
Compare
F

L

E

X
The Liquiphant FTL64 ensures long term reliable detection

F

L

E

X

Products

Level

A level switch for hot and pumpable liquids

Predecessor: Liquiphant S FTL70 , Liquiphant S FTL71

Show specs at a glance Hide details

Process temperature

-60 °C...+280 °C
(-76 °F...+536 °F)

Process pressure absolute / max. overpressure limit

Vacuum...100 bar
Vacuum...1450 psi

Min. density of medium

0.5 g/cm³
(0.4 g/cm³ optional)
Loading price

Prices temporarily unavailable

Price after login

Price on request

from CHF ??.-
Compare
F

L

E

X
Capacitance
Point level detection
Liquipoint FTW23

F

L

E

X

Products

Level

Cost effective point level switch for water-based liquids

Predecessor: Pump Protection FTW360

Show specs at a glance Hide details

Process temperature

Standard:
-20 ... 100°C
Cleaning:
-20 ... 135°C for 1h
-4 ... 275F for 1h

Process pressure absolute / max. overpressure limit

Vacuum ... 16 bar
Vacuum ....232 psi
Loading price

Prices temporarily unavailable

Price after login

Price on request

from CHF ??.-
Compare
